EdgeClaw: Edge-Cloud Collaborative Personal AI Assistant based on OpenClaw

【中文 | English】

News

• [2026-02-12] 🚀🚀🚀 We open-source EdgeClaw, an edge-cloud collaborative AI assistant based on OpenClaw

Overview

EdgeClaw is an edge-cloud collaborative personal AI assistant, jointly developed by THUNLP, Renmin University of China, AI9Stars, ModelBest and OpenBMB, built on top of OpenClaw.[1]

Designed to tackle the AI Agent data leakage challenge, EdgeClaw provides a comprehensive, customizable three-tier security system (S1 passthrough / S2 desensitization / S3 local). It standardizes safety guardrails into a universal GuardAgent Protocol (Hooker → Detector → Action). Combined with intelligent edge-cloud routing capabilities, developers can achieve seamless privacy protection — "public data to the cloud, private data stays local" — within OpenClaw without modifying any business logic, balancing the peak performance of large models with absolute security of sensitive data.

[1] OpenClaw：https://github.com/openclaw/openclaw

Demo

Installation

Same as OpenClaw:

1. Clone the Repository

git clone https://github.com/openbmb/edgeclaw.git
cd edgeclaw

2. Install Dependencies + Build

pnpm install
pnpm build
pnpm ui:build
pnpm openclaw --install-daemon

3. Install the Extension

GuardClaw is included in the extensions/guardclaw directory. Enable it in your openclaw.json configuration:

{
  "plugins": {
    "entries": {
      "guardclaw": {
        "enabled": true,
        "config": {
          "privacy": {...}
        }
      }
    }
  }
}

4. Configure Guard

Edit the privacy field under plugins.entries.guardclaw.config in openclaw.json (see the Customization section below for full details):

{
  "privacy": {
    "enabled": true,
    "localModel": {
      "enabled": true,
      "provider": "ollama",
      "model": "openbmb/minicpm4.1",
      "endpoint": "http://localhost:11434"
    },
    "guardAgent": {
      "id": "guard",
      "workspace": "~/.openclaw/workspace-guard",
      "model": "ollama/openbmb/minicpm4.1"
    }
  }
}

Also, add a list field under the agents section in openclaw.json:

"list": [
  {
    "id": "main",
    "workspace": "~/.openclaw/workspace-main",
    "subagents": {
      "allowAgents": ["guard"]
    }
  },
  {
    "id": "guard",
    "workspace": "~/.openclaw/workspace-guard",
    "model": "ollama/openbmb/minicpm4.1"
  }
]

5. Start Ollama

# Install Ollama (if not already installed)
# macOS: brew install ollama
# Linux: curl -fsSL https://ollama.ai/install.sh | sh

# Pull the model
ollama pull openbmb/minicpm4.1

# Start the service (default port 11434)
ollama serve

Then start OpenClaw as usual:

pnpm openclaw gateway run

GuardClaw will automatically intercept and route sensitive requests.

Customization

GuardClaw supports custom configuration, rules, and more:

JSON Configuration — Rules & Models

Edit the privacy field under plugins.entries.guardclaw.config in openclaw.json:

Custom Detection Rules

{
  "privacy": {
    "rules": {
      "keywords": {
        "S2": ["password", "api_key", "token", "credential"],
        "S3": ["ssh", "id_rsa", "private_key", ".pem", "master_password"]
      },
      "patterns": {
        "S2": [
          "\\b(?:10|172\\.(?:1[6-9]|2\\d|3[01])|192\\.168)\\.\\d{1,3}\\.\\d{1,3}\\b",
          "(?:mysql|postgres|mongodb)://[^\\s]+"
        ],
        "S3": ["-----BEGIN (?:RSA |EC )?PRIVATE KEY-----", "AKIA[0-9A-Z]{16}"]
      },
      "tools": {
        "S2": {
          "tools": ["exec", "shell"],
          "paths": ["~/secrets", "~/private"]
        },
        "S3": {
          "tools": ["system.run", "sudo"],
          "paths": ["~/.ssh", "/etc", "~/.aws", "/root"]
        }
      }
    }
  }
}

Custom Checkpoints & Detector Types

Control which detectors run at which stage:

{
  "privacy": {
    "checkpoints": {
      "onUserMessage": ["ruleDetector", "localModelDetector"],
      "onToolCallProposed": ["ruleDetector"],
      "onToolCallExecuted": ["ruleDetector"]
    }
  }
}

• ruleDetector — Fast rule-based detection
• localModelDetector — LLM-based semantic understanding (~1–2s), recommended for onUserMessage

Custom Models

{
  "privacy": {
    "localModel": {
      "enabled": true,
      "provider": "ollama",
      "model": "openbmb/minicpm4.1",
      "endpoint": "http://localhost:11434"
    },
    "guardAgent": {
      "id": "guard",
      "workspace": "~/.openclaw/workspace-guard",
      "model": "ollama/openbmb/minicpm4.1"
    }
  }
}

Any Ollama-compatible model is supported. Models with 8B+ parameters are recommended for classification accuracy.

Custom Markdown Prompts — Classification & Behavior

Three Markdown files in the prompts/ directory can be edited directly to change GuardClaw's behavior:

prompts/detection-system.md — Classification Rules

Controls how the LLM classifies S1/S2/S3. You can:

• Adjust classification criteria for each level
• Add specific sensitive data types
• Modify edge-case decision rules

prompts/guard-agent-system.md — Guard Agent Behavior

Controls how the S3 local model responds. You can:

• Adjust response style and verbosity
• Add domain-specific analysis instructions
• Modify language rules
• Integrate with the original OpenClaw system prompt, etc.

prompts/pii-extraction.md — Sensitive Information Extraction Rules

Controls which sensitive information types are extracted during S2 desensitization. You can:

• Add new sensitive information types (e.g., industry codes, internal IDs)
• Adjust extraction examples to improve accuracy

After modifying .md files, the built-in fallback mechanism ensures changes take effect on the next request — no restart needed.

GuardAgent Protocol Specification

GuardAgent Protocol is a privacy-security middleware protocol for AI Agent frameworks, defining how sensitive data is detected, classified, and processed throughout the Agent lifecycle.

Formal Definitions

Basic Sets

Let the following basic sets exist in an Agent system:

• Privacy level set ℒ = {S₁, S₂, S₃}, equipped with a total order S₁ ≺ S₂ ≺ S₃, where S₁ denotes no private data, S₂ denotes desensitizable private information, and S₃ denotes deeply private data.
• Checkpoint set 𝒞 = {c_msg, c_route, c_{tool_pre}, c_{tool_post}, c_persist, c_end}, corresponding to the six lifecycle stages: message received, model routing, pre-tool-call, post-tool-call, result persistence, and session end.
• Detector set 𝒟 = {d_rule, d_model}, where d_rule is a rule-based detector using regex and keywords, and d_model is a semantic detector based on a local language model.
• Action set 𝒜 = {passthrough, desensitize, redirect}, representing pass-through, desensitize-then-forward, and redirect-to-local-model respectively.

Definition 1: Detection Function

Each detector d ∈ 𝒟 is defined as a function mapping context to a privacy level:

d : 𝒳 → ℒ

where context x ∈ 𝒳 may contain message content, tool call information, file contents, etc., depending on the checkpoint type. Specifically, the rule detector d_rule performs deterministic matching based on a predefined rule set ℛ = {r_l}_{l ∈ ℒ}, and the model detector d_model uses a local LLM θ_local for semantic classification.

At checkpoint c ∈ 𝒞, the configuration function Φ(c) ⊆ 𝒟 returns the subset of detectors enabled for that checkpoint. All detectors run in parallel, and the aggregated result takes the highest level:

Detect(x, c) = max_≼ { d(x) | d ∈ Φ(c) }

Definition 2: Routing Function

The routing function R maps detection results to the action space, determining how a message is processed:

R : ℒ → 𝒜

         ⎧ passthrough    if l = S₁
R(l)  =  ⎨ desensitize    if l = S₂
         ⎩ redirect       if l = S₃

Definition 3: Desensitization Function

For S₂-level content, the desensitization function De maps raw content containing private information to safe content:

De : ℳ_raw → ℳ_safe

Constraint: all privacy entities in the original content m are replaced with irreversible desensitization tokens, the output De(m) contains no original private information, while preserving semantic usability.

Definition 4: Dual-Track Persistence

Define two history tracks H_full (complete) and H_clean (sanitized). The persistence function W selects a write strategy based on the privacy level:

            ⎧ H_full ← m,  H_clean ← m        if l = S₁
W(m, l)  =  ⎨ H_full ← m,  H_clean ← De(m)   if l = S₂
            ⎩ H_full ← m,  H_clean ← ⊥        if l = S₃

where ⊥ denotes a placeholder (e.g., 🔒 [Private content]).

The cloud model θ_cloud can only see H_clean, while the local model θ_local can see H_full:

θ_cloud.context = H_clean ,   θ_local.context = H_full

Definition 5: Memory Synchronization

At session end, the synchronization function Sync performs bidirectional updates between the dual-track memories M_full and M_clean:

Sync:   M_clean = De( Filter( M_full ) )

where Filter removes Guard Agent interaction content, and De performs final desensitization on residual private information.

End-to-End Pipeline

A user message m passes through the full GuardAgent Protocol processing pipeline:

                                                    ⎧ θ_cloud(m)        if a = passthrough
m ─[c_msg]→ Detect(m) → l ─[c_route]→ R(l) → a → ⎨ θ_cloud(De(m))    if a = desensitize
                                                    ⎩ θ_local(m)        if a = redirect

  ─[c_persist]→ W(m, l) ─[c_end]→ Sync

Security Guarantees

Let x be an arbitrary data unit (message m or memory entry e), and Cloud(x) denote the visible form of x on the cloud side (including View(θ_cloud) and M_clean).

Theorem 1 (Cloud Invisibility): For any S₃-level data unit x, its original content is completely invisible on the cloud side:

∀ x,   Detect(x) = S₃  ⟹  x ∉ Cloud(x)

Theorem 2 (Desensitization Completeness): For any S₂-level data unit x, its cloud-visible form contains no original privacy entity values:

∀ x,   Detect(x) = S₂  ⟹  ∀ (t_i, v_i) ∈ Extract(x),   v_i ∉ Cloud(x)

Design Structure

Multi-Hooker

6 hooks cover the complete Agent lifecycle:

User Message  ──▶ ① message_received     Detect message sensitivity
                        │
              ② resolve_model             ★ Core routing: S1→cloud / S2→desensitize→cloud / S3→local
                        │
Tool Call     ──▶ ③ before_tool_call      Intercept sensitive paths/tools
                        │
Tool Result   ──▶ ④ after_tool_call       Detect returned content
                        │
Persistence   ──▶ ⑤ tool_result_persist   Write to dual-track history
                        │
Session End   ──▶ ⑥ session_end           Synchronize memory files

Dual Session

~/.openclaw/agents/main/sessions/
├── full/                    ← Complete history (local model + audit)
│   └── session-abc.jsonl       All messages, including local model interactions
└── clean/                   ← Sanitized history (cloud model)
    └── session-abc.jsonl       Sensitive content filtered out

• Normal messages → written to both full + clean
• Sensitive messages → written to full only, invisible in clean
• Cloud model loads clean history, local model loads full history

Dual Memory

workspace/
├── MEMORY.md           ← Visible to cloud model (filtered)
├── MEMORY-FULL.md      ← Visible to local model (complete)
├── memory/             ← Cloud memory directory
└── memory-full/        ← Local memory directory

Automatic synchronization at session end: MEMORY-FULL.md → filter sensitive content → MEMORY.md

License

MIT

Contributing

Thanks to all contributors for their efforts in code submissions and testing. We welcome new members to join and build a robust edge-cloud collaborative agent ecosystem together!

Contact Us

• If you have any questions, feedback, or would like to get in touch, please use GitHub Issues.
